| Line Frequency | 50 or 60
Hz
|
| Input Voltage | 220 to 240
V
|
| Cable | Cable 1.5 m with plug
|
| Inrush current | 23.8
A
|
| Power Consumption | 48
W
|
| Initial CLO power consumption | -
W
|
| Connection | Connection unit 2-pole
|
| Inrush time | 0.12
ms
|
| Average CLO power consumption | -
W
|
| Number of products on MCB of 16 A type B | 24
|
| Power Factor (Fraction) | 0.9
|
| Input Frequency | 50 or 60
Hz
|
| Median useful life L90B50 | 20,800
hour(s)
|
| Median useful life L70B50 | 71,500
hour(s)
|
| Driver failure rate at 5000 h | 0.003
%
|
| Median useful life L80B50 | 44,400
hour(s)
|
| Numerator - Quantity Per Pack | 1
|
| EAN/UPC - Case | 8710163341484
|
| Material number (12NC) | 911401808480
|
| Order code | 911401808480
|
| Full product code | 871016334146099
|
| Full product name | RC091V LED48S/840 PSU W60L120 G2 CL
|
| Numerator - Packs per outer box | 2
|
| Order product name | RC091V LED48S/840 PSU W60L120 G2 CL
|
| Mech. impact protection code | IK02
[0.2 J standard] |
| Warranty period | 5 years
|
| EU RoHS compliant | No
|
| Ingress protection code | IP20
[Finger-protected] |
| Protection class IEC | Safety class II
|
| CE mark | CE mark
|
| Flammability mark | -
|
| ENEC mark | -
|
| Glow-wire test | Temperature 650 °C, duration 30 s
|
| Dimmable | No
|
| Constant light output | No
|
| Driver/power unit/transformer | Power supply unit (ON/OFF)
|
| Control interface | -
|
| Light source replaceable | No
|
| Light source engine type | LED
|
| Number of gear units | 1 unit
|
| Driver included | Yes
|
| Housing Material | Aluminum extruded
|
| Housing Color | White
|
| Overall height | 10
mm
|
| Optical cover/lens finish | Opal
|
| Fixation material | -
|
| Optic material | Polystyrene
|
| Reflector material | -
|
| Overall width | 595
mm
|
| Optical cover/lens material | Polystyrene
|
| Overall length | 1,195
mm
|
| Dimensions (Height x Width x Depth) | 10 x 595 x 1195 mm
|
| Maximum dim level | Not applicable
|
| Suitable for random switching | Not applicable
|
| Initial chromaticity | (0.3818;0.3797), SDCM≤5
|
| Luminous flux tolerance | +/-10%
|
| Power consumption tolerance | +/-10%
|
| Ambient temperature range | -10 to +35 °C
|
| Beam angle of light source | 120
degree(s)
|
| Optic type | Beam angle 120°
|
| Luminous Flux | 4,800
lumen
|
| Light source color | 840 neutral white
|
| Luminous Efficacy (rated) (Nom) | 100
lm/W
|
| Correlated Color Temperature (Nom) | 4000
K
|
| Color rendering index (CRI) | >80
|
| Optical cover/lens type | Opal
|
| Luminaire light beam spread | 120°
|
