    • CoreLine Batten – the clear choice for LED

      BN126C LED25S/840 PSU L1200
      LED
      BN126C LED25S/840 PSU L1200
      CoreLine Batten

      BN126C LED25S/840 PSU L1200

    Specifications Show all

    Operating and Electrical
    Line Frequency
    50 or 60 Hz
    Input Voltage
    220-240 V
    Cable
    -
    Inrush current
    8.3 A
    Power Consumption
    18 W
    Connection
    Push-in connector 3-pole
    Inrush time
    0.332 ms
    Number of products on MCB of 16 A type B
    25
    Input Frequency
    50 or 60 Hz
    Power Factor (Fraction)
    0.9
    Product Data
    Numerator - Quantity Per Pack
    1
    EAN/UPC - Case
    8719514948983
    Material number (12NC)
    911401833784
    Order code
    911401833784
    Full product code
    871951494876199
    Full product name
    BN126C LED25S/840 PSU L1200
    Numerator - Packs per outer box
    8
    Order product name
    BN126C LED25S/840 PSU L1200
    Over Time Performance (IEC Compliant)
    Lumen maintenance at median useful life* 100000 h
    70
    Lumen maintenance at median useful life* 50000 h
    85
    Control gear failure rate at median useful life 50000 h
    5 %
    Approval and Application
    Sustainability rating
    -
    Mech. impact protection code
    IK04  [0.5 J standard plus]
    Photobiological risk specification
    0.2 m
    Warranty period
    5 years
    EU RoHS compliant
    Yes
    Ingress protection code
    IP20  [Finger-protected]
    Protection class IEC
    Safety class I
    CE mark
    CE mark
    Photobiological risk
    Photobiological risk group 0 @200mm to EN62778
    Flammability mark
    For mounting on normally flammable surfaces
    Glow-wire test
    Temperature 650 °C, duration 30 s
    ENEC mark
    ENEC mark
    Controls and Dimming
    Constant light output
    No
    Dimmable
    No
    Driver/power unit/transformer
    Power supply unit (On/Off)
    Control interface
    -
    General Information
    Feed-through wiring
    Simple Connection and removable cover available for feed-through wiring 1-phase (internal wiring is not included)
    Light source replaceable
    No
    Number of gear units
    1 unit
    Driver included
    Yes
    Value ladder
    Performance
    Lighting Technology
    LED
    Mechanical and Housing
    Housing Color
    White
    Housing Material
    Steel
    Optical cover/lens finish
    Opal
    Reflector material
    -
    Fixation material
    -
    Optic material
    Polycarbonate
    Overall length
    1,135 mm
    Overall width
    65 mm
    Optical cover/lens material
    Polycarbonate
    Dimensions (Height x Width x Depth)
    65 x 65 x 1135 mm
    Overall height
    65 mm
    Application Conditions
    Suitable for random switching
    Not applicable
    Performance ambient temperature Tq
    25 °C
    Initial Performance (IEC Compliant)
    Initial chromaticity
    (0.38, 0.38) SDCM≤3
    Power consumption tolerance
    +/-10%
    Luminous flux tolerance
    +/-10%
    Temperature
    Ambient temperature range
    -20 to +40 °C
    Light Technical
    Optic type
    Beam angle 120°
    Saturated Red (R9)
    <50
    Luminous Flux
    2,500 lumen
    Correlated Color Temperature (Nom)
    4000 K
    Color rendering index (CRI)
    >80
    Luminous Efficacy (rated) (Nom)
    130 lm/W
    Light source color
    840 neutral white
    Unified glare rating CEN
    26
    Stroboscopic effect value (SVM)
    1.6
    Luminaire light beam spread
    120°
    Flickering value (PstLM)
    1
    Installation Diagrams
     840 neutral white - Power supply unit
    840 neutral white - Power supply unit
    Downloads
    Product Data Sheets
    Visuals
    Brochures
    Software Plugins
    • IES IES File - BN126C LED25S/840 PSU L1200 IES 14.3 kB
